Description

• 100% bolt on design, no drilling or welding required!
• All tube parts are DOM with .120 wall thickness for increased strength and dent resistance.
• Frame mounting plates and gussets are .188 thickness.
• Outer round tube is sloped up at 25 degrees with flat step plates (level to the ground).
• Main slider support legs are welded in at a 45 degree rotation to help prevent the slider from getting hung up on sharp rocks.
• All mounting hardware is grade 10.9 and included with the purchase.
• Dimple died step plates give traction for standing and clean out easily when driving in mud or snow.
• Removable step plates make painting easier and allow for multiple different coating options.
• Welded on step plates are not currently an option.
• Screws are zinc plated steel, Torx, pan head, 10-24 self threading screws.
• Not compatible with Limited models or 2022 Sport models
• Sliders with step plates weigh 65lbs each, without step plates weigh 60lbs each.
• SHIPS BARE STEEL, C4 does not offer powder coating services. Bumper will need to be painted or powder coated before installation to prevent rust.
